I am deleighted to say that we are physically exhibiting at LCV2021 this year. Please come along to our stand (C4-307) and you can see our innovative PEN-GUARD® unit being subjected to some horrible mains voltage waveforms. We also have example High Voltage Junction / Power Distribution systems on display as well as motor drives and other power electronics sytems we have developped over the years.
https://www.smartpowersolutions.com/wp-content/uploads/2019/06/LCV.jpeg225225spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152021-09-14 10:04:332021-09-20 20:07:12LCV2021 – We are on stand C4-307
We are very excited to be involved in LCV2020 as an exhibitor. Looks like the virtual booth doesnt have a web chat which comes as a surprise. For today please use the MS Teams link here if you want to video chat with our technical partner Dr Charlie Elliott. We will post another one tomorrow.
We are delighted to announce that we be participating in the online version of LCV on 18th and 19th November 2020 . It is a great shame that this well attended and fantastic event can’t happen physically this year. However we have a virtual booth to give you a better feel for the advanced motor-drives and other power conversion equipment we can design and manufacture. Please do come and visit and have a virtual chat. We will also be launching the first of our own products for EV charging installation protection via our suster company Smart Power Products. Lots more to come on that.
Our Technical Partner (Dr Charlie Elliott) had a busy end to last week getting in a grant application to Innovate UK. It is great to see that UK Gov / IUK has responded rapidly to the current crisis. It is running a short turn-around 100% funded grant scheme for up to £50k to be spent within 6 months. SPS has applied to allow it to design an innovative power electronics controller for use a wide variety of applications. The grant will cover the hardware design and prototyping.
SPS gets many enquiries where the volumes don’t justify a fully custom solution. Using a common controller but with bespoke power electronics is a very useful half-way house. It should allow SPS to win more projects and thereby sustain it going forward and hopefully expand!! The controller will support many different applications but will be principally aimed at niche vehicle electrification projects such as emergency vehicles, rail works trains, construction and mining equipment. The hardware and software will support not only motor drives but also ACDC and DCDC power conversion requirements.
If we are granted the funding, we will be kicking the project off in about 4 weeks times. We anticipate having the controller ready for use by the end of 2020. If you think this is of interest to you then please do make contact and we can give you more information in terms of specification and cost targets.
https://www.smartpowersolutions.com/wp-content/uploads/2020/01/IUK.png220220spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-04-20 08:19:312020-04-19 08:47:53Innovate UK Grant Application
SPS continues to function as effectively as possible during these challenging times in order to support our staff, customers and economy. The safety of our staff is of course paramount. As requested by UK government, where possible they are working from home. All staff have access to all their normal design tools and resources. Please use e-mail as first means of contact.
Where manufacturing or test/validation work is involved, staff will be in work. We have plenty of space so can easily meet the 2m safe “social distancing” advice. We have also taken additional steps to minimise risk as best as possible in terms of delivery hygiene and additional cleaning etc.
The partners of SPS would like to reassure its customers (and prospective ones) that the business is in a good position to weather this storm both in terms of its finances and its logistics. We have been in contact with our key suppliers and in the vast majority of cases they working although with slightly increased lead-times.
Be safe everybody and let’s hope that some positives can come out of this!!
Recently our Commercial Partner (Ms Patricia Elliott B.Eng) was kindly given an item by the company she used to work for (Nidec SR Drives Ltd.). It was the last product she worked on before she left to set up Smart Power Solutions with our Technical Partner (Dr. Charlie Elliott). It is a high-power commercial vacuum cleaner unit used in larger homes and hotels in the US.
In order to keep size down and allow for long-life, a high-speed 2-phase Switched Reluctance Motor was used. To minimise input current whilst keeping cost low, a valley-fill power-factor improvement circuit was used. The control was implemented in a sub $1 microcontroller. As far as we are aware, nobody else has ever implemented such an innovative motor drive for this application since. When it was powered up in our lab, it worked after being sat in storage for almost 20 years!!
SPS is very well positioned to carry out motor drive development on all conceivable motor types. It has experience from low power 20W fans all the way up to 1MW mining applications. You won’t be surprised to hear that SPS is heavily involved in electrification of transport projects for both on and off-road use.
Innovative Motor Drive
https://www.smartpowersolutions.com/wp-content/uploads/2020/03/20200309_150241-rotated.jpg21602160spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-03-10 08:52:232020-03-10 08:52:23Motor Drive Development – Still innovative after 20 years!!
Our Technical Partner Dr. Charlie Elliott visited Dynex in Lincoln yesterday. As well as a general catch up he wanted to discuss possible technical collaboration utilisting SPS’s experience with power electronics systems development. Charlie first came across Dynex when they were GEC Plessy Semiconductors as a graduate trainee at GEC Electrial Projects in 1991. It is about 15 years since he last visited and he reported that is was great to see them thriving with investment from majority Chinese owners CRRC. Not only are they busy with manufacturing their existing range of power semiconductors, but they are pushing hard to improve them.
Their power assemblies unit is continuing with its excellent reputation for supplying specialist traction refurbishment and other high power applications. It operates at power levels well above what SPS can manufacture so there is no real overlap. SPS is hoping it can complement what Dynex already does and assist with power electronics systems when their customers are looking for this capability.
https://www.smartpowersolutions.com/wp-content/uploads/2020/03/Dynex.jpeg200200spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-03-04 08:25:202020-03-04 08:25:20Visit to Dynex
During the 18 years SPS has been in business, it has developed a hugely diverse range of products for its customers. These have covered mW to MW (careful with the capitalisation!!) in areas such as Medical, Automotive, White Goods, Oil & Gas, Railways and Industrial. All of them have a general theme of using electronics to control power and ususally with software. SPS has a very straightforward commercial model with respect to the design rights – if you pay for it you own it!! In all cases to date, our customers have chosen to own the design.
Over the years we have seen a few niche opportunities that we have wondered whether we should exploit independently. We believe now is the time to do this but of course being careful not to compete with our customers and making sure we still have enough resource to properly look after them. We will be initially focusing on products we can manufacture ourselves but also looking at designs we could licence or subcontract if volumes are higher.
When we are further down the road with these in-house products, we will be publishing some details and looking for early adopters. Meanwhile, if you can think of a niche power related product that you can see a need for then please do get in contact.
https://www.smartpowersolutions.com/wp-content/uploads/2018/02/SPS_Logo_Square.jpg24812481spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-02-17 10:19:302020-02-17 13:45:48SPS is developing it’s own products!!
We are delighted to be able to report that SPS has yet again been awarded the status of Premier Design Partner by Microchip Technology. We use their parts (mainly 16 bit dsPICs + analogue parts) on the majority of the work we carry out due to the excellent performance, choice, cost and availability of their parts. Being a Premium Partner also means we get priority technical support and advance notification of new parts and technology. Both of these things are very important to provide the best possible service to our customers. Not wishing to be big headed, but SPS is the only Premier Design Partner with Motor Control Expertise in Europe and the only one worldwide with this ranking for both Motor Control and Functional Safety.
https://www.smartpowersolutions.com/wp-content/uploads/2020/02/PartnerLogo_Web-authorized.png300300spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-02-14 16:41:542020-02-14 16:41:54SPS awarded Premier Design Partner Status Again
Our Technical Partner Dr Charlie Elliott had a very fruitful discussion with a key supplier (ST) this morning. This was to mainly discuss a new automotive EV inverter enquiry but to also get an update on all sorts of things. Charlie caught up with Keith D’Souza who he has known for well over 15 years. It turns out that on Friday Keith will have been with ST for 30 years. Many congratulation to you Keith!!
Charlie spends a fair bit of time ensuring that SPS maintains it’s excellent direct links with key component suppliers and makes sure they stay up to date with latest technology trends and product offerings.
https://www.smartpowersolutions.com/wp-content/uploads/2020/02/ST_logo2.jpeg400400spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152020-02-12 13:26:072020-02-12 13:26:27Visit by key supplier – ST to discuss SiC and other things.
Our Technical Partner (Dr. Charlie Elliott) visited the Compound Semiconductor Application Catapult in Newport last week. He commented that is was great to see the fantastic team and facilities that are rapidly being established there. We are very much looking forward to working with them on future projects and already have a perfect application that could involve them for high voltage and high power (muti-MW) systems.
Two of our Principal Engineers have just come back from being on site at Newcastle University School of Electronic and Electrical Engineering. They were utilising the excellent dynamometer facilities that are installed there. The motor under test was a high pole-count (66!) permanent magnet type which is controlled by a bespoke high-reliability and rugged inverter SPS designed and manufactured for its client. The high torque (1800Nm) system performed very well and pushed the dyno well above where it had ever previously been used since it was installed.
In the new year SPS will be working on updating the software and control interface for the end application and then going on-site with our customer to test the system in the final application.
https://www.smartpowersolutions.com/wp-content/uploads/2020/01/torque_motor.jpg10001000spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152019-12-17 16:01:012020-01-25 16:24:15High torque motor drive system testing
SPS has just completed supplying the first batch of traction power converters used by Clayton Equipment in their innovative full-electric and hybrid locomotives. They are rated at up to 180 kW and suitable for use at up to 750 V DC (max) with IP68 rating. Specific steps have been taken with the design to ensure high reliability with the inevitable power cycling such units experience in operation.
Unusually, these are air-cooled to provide packaging flexibility and improve reliability vs a liquid cooled approach. The fans maintain the IP68 rating and give several years of life before servicing is required. The converters can be supplied liquid cooled if required.
SPS is very well placed to both design and manufacture specialist power conversion equipment for lower-volume demanding applications. Please contact us if this is something you are interested in.
https://www.smartpowersolutions.com/wp-content/uploads/2019/12/SPS126_6-Sh9-ph1.jpg768965spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152019-12-09 13:44:542020-01-24 15:34:58Traction Power Converters Shipped
Today was our annual external audit by BSI for our ISO9001:2015 quality management system. I am pleased to report that we passed with flying colours with no non-conformities at all. We did have an interesting discussion with our auditor on the subject of collaborative working. For certain this is the manner in which we prefer to work with our customers as it benefits both parties. He kindly told us about the Institute of Collaborative Working and the fact there is a specific standard and accredition (ISO 44001:2017) available. Perhaps something to consider for the future!! Meanwhile our training program will continue to make sure out staff have the relevent skills required.
SPS has just started testing the latest version of the highly challenging PCB it has designed for an automotive SiC-based EV inverter. The PCB not only implements all the required gate drive but integrates many other essential sensing and other auxiliary features to ensure electrical and functional safety. The space available for the PCB is very tight, the DC voltage high (up to 900V) and it has to press-fit to a power module where all the connection locationss are already set. The combined effect of this is that it has really challenged our most experienced PCB layout designer who has 25+ years experience.
The entire development of the PCB has been done in-house including the validation testing and manufacture of prototype PCBs. Given SPS’s senior staff have been working on xEV systems for well over 20 years, it is not surprising that our end customer has also asked us to assist with many other areas of their development. This includes advice on electrical / functional safety, EMC mitigation measures and thermal management. SPS has also carried out critical testing of the inverter system including full double pulse switch testing over the entire range of voltages, current and temperatures. This is an essential aspect of power electronics development that is unfortunately either skipped entirely or not done thoroughly by many other companies. This can result in an unacceptable amount of unknown risk in a product leading to reliability problems in the field. Most certainly not an option for an automtive product!! Please do contact us if our facilities and experience could be of use to your company.
SPS has now completed the IUK funded project with it’s long term customer Ceres Power that began in July 2017. SPS’s part of the project was associated with a low-cost 1kW isolated DC to AC grid tied inverter system for use on Fuel Cell based micro combined heat and power residential applications. SPS’s two main objectives for the project were:
To increase efficiency (without adding undue additional cost) targeting 92% at full power from low voltage DC in to 230V AC mains out. This is quite a tough target as two series power conversion stages are required for the application.
To build in the necessary hardware to support new grid connection standards for the UK and other geographic markets.
We are delighted to report that using one of our calibrated digital power meters, the efficiency was measured at 92.1% once the unit had reached its final temperature. This efficiency was achieved using low-cost silicon power semiconductor technology rather than using the latest “Wide-bandgap” devices. The latter is too expensive for the target application at this point in time. However, the new design is flexible enough to be upgraded with minimal effort when this situation changes in the future. Efficiencies of more like 95% will then be achievable.
SPS is now looking to exploit what it has learned through this project both from the core power electronics and the grid connectivity requirements. Please do get in contact if this is of interest. A photo of one of the prototypes that were produced in house is shown below.
https://www.smartpowersolutions.com/wp-content/uploads/2020/01/IUK.png220220spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152019-08-09 11:11:262020-01-24 13:32:30Innovate UK Project a Success!!
The control of electrical power is fundamental to what SPS does and has inevitable safety implications not just in its raw form but also in terms of what it allows you to do to effect motion etc. It is something that SPS takes very seriously in all aspects of what it does to protect its staff, customers and end users. This is epecially so in certain sectors such as automotive, medical, railways and industrial where over the years formal functional safety standards have evolved.
SPS has recently been officially recognised by Microchip as having sufficient experience in this area to become one of select few functional safety design partners. SPS uses Microchip products to implement all of its embedded control partly as they have products with the required features and tools/libraries available to aid meeting safety requirements. A summary of their capabilities can be found here.
We will be continuing to expand our expertise in this area by investing in training and the relevant processes and software tools especially with respect to software development and testing.
Not quite sure why it has worked out like this but June seems to be the month for Training this year. First of all one of our Principal Engineers (Peter Moriarty) went on a 4 day course run by Ridley Engineering on Power Supply Design. This is a world reneowned course run by one of the leaders in the SMPS industry which is both theoretical and hands on.
Next our production staff are renewing their IPC qulifications in IPC A-610 – Acceptability of Electronic Assemblies and IPC WHMA-A-620 – Requirements and Acceptance for Cable and Wire Harness Assemblies
All of staff have a target of doing at least 1 day training a year. Sometimes this is in the form of internal mentoring but where possible we try to find external courses so we can expand our knowledge within the company. This is one of our stated QMS objectives.
https://www.smartpowersolutions.com/wp-content/uploads/2019/06/Staff-Training-figure-tojpeg_1548859010894_x2.jpg648630spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152019-06-07 15:05:132019-06-08 15:08:43June is Training Month at SPS
May in Nuremberg – must be time for PCIM again!! This year as well as our Technical Partner Dr. Charlie Elliott, our Production and Quality Manager Alan Yarker also attended. Sadly no sitting outside drinking cold beers this year and thanks to KLM it was a bit of a truncated visit but still well worth while. Very good to see there is more than just marketing hype to the introduction of Wide Band Gap semiconductors. Very notable increase in the number of major players with physical parts now in modules. Availability and cost are still major issues but things are improving on both fronts. It was great to catch up with many of our key suppliers, find a new one or two and even chat with competitors. PCIM is still the go to event as far as we can see. Can’t say we have ever been to APEC but am seriously considering it for next year.
Our Technical Partner Dr. Charlie Elliot has been involved in this cross industry initiative for quite some time as it originated in Power Electronics UK. He recently attended a key update meeting in Birmingham. A detailed video giving more details can be found here. Subject to business case and match funding from industry, government has announced that it is prepared to invest up to £78 million in this challenge. This will be managed through Innovate UK and the Industrial Strategy Challenge Fund – wave 3.
The challenge is all about developping a UK supply chain for power electronics machines and drives across 7 industrial sectors. All 7 sectors are cruicial if we are to hit our future emmissions targets whilst mainting or exceeding the standard of life we are all used to. We will be keeping a close eye as things develop as this major initiative is something SPS would very much like to be part of and is very well placed both in terms of experience and facilities.
https://www.smartpowersolutions.com/wp-content/uploads/2019/06/s300_is.jpg195300spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152019-02-14 13:33:542019-06-08 20:40:51Stephenson Challenge / Driving the Electric Revolution
Our Technical Partner Dr Charlie Elliott attended the second Cenex / Level Vehicle to Grid (V2G) workshop held in Nottingham on 6th February. It was a follow on event from the one in 2018 and it was great to see presentations on the outcome from real world installations abroad and in the UK. As last year there was some healthy debate as to the real world commercial feasibility of V2G in the UK. In other countries certain markets for services have artifically high prices which makes V2G a much simpler proposition.
Courtesy of a £30M Innovate UK funded project there is a lot of activity in this area at the moment which is great to see but also a bit frustrating for a UK based power electronics design and manufacturing company not even contacted to be involved!! One project in particular promises to install up to 1k V2G systems for domestic use. Sadly the core power electronics of this and other systems within the IUK project are being bought in from abroad presumably as there was thought to be insufficient time/budget/knowledge to carry out the development in the UK. Driving down the price of the hardware for V2G is essential to make it commercially viable. SPS is exceptionally well-placed to carry out such work given its existing experience in bidirectional grid-tied inverters and DCDC converters built up over many years. It has also previously worked on DC rapid chargers for EVs. SPS is currently investigating sources of funding / partners for such activity. If you are interested then please do get in contact.
Our Technical Partner Dr. Charlie Elliott has just come back from Brazil where he sucessfully commissioned an ultra-compact high-efficiency motor-drive inverter based on SiC MOSFETs. This 15kW system hit 98% efficiency which is fairly special in it’s own right. If you then add the fact that the system has to work at 330 bar pressure on the bottom of the sea bed then you probably have a world first!! Charlie was testing the system flooded with pressure compensating oil in a special test chamber in Rio de Janeiro.
We had our first external audit of our ISO9001:2015 QMS by BSI since we made the 2008-2015 transition yesterday. I am pleased to announce that we passed with no issues at all, not even a minor non-conformance. Well done to all involved. Two “Opportunities for Improvement” were made that we will be taking on board in due course. We will publish the new certificate when it comes available on our quality page.
Out Technical Partner Dr. Charlie Elliott decided to get in the spirit of things and take his own 30kWh Nissan Leaf to LCV this year. It wasn’t just for the free parking (although he has been in Yorkshire for over 30 years so something must have rubbed off by now) but also as a bit of a show of solidarity. Two stops for 20 mins each on the way there and back to rapid charge was no issue at all with a coffee and a few e-mails written each time. Charging was free at the event and he even made use of the measured mile at Milbrook to see how the leaf did – a ton wasnt a problem! He reported that LCV has grown again and it was great to see so many UK based outfits working hard in the Low Carbon Vehicle sector. We may have to think about taking a stand next year.
We are delighted to report that we have just kicked off another significant project using SiC MOSFETs. In the past 18 months we have been working on two SiC based motor drive systems. One is for an EV project where the attraction of SiC is the power density and part load efficiency benefits. The latter in particular is essential as it offers potential for reduction in battery pack capacity/size/cost or alternatively additional range. The other existing project is for an ultra high-efficiency motor drive where size is especially important and cost less so.
This new project is for higher power 500 kVA static-power conversion system where being able to switch at 20 kHz and above is essential to reduce the size of filtering components and eliminate switching frequency audible noise. Up at these kinds of power / current levels there is no choice but to parallel commercially available power modules. This brings it’s own challenges in terms of gate drive function and power circuit layout to ensure sharing of losses and to eliminate the potential for the modules to oscillate against each other. SPS will be using it’s wealth of experience in core power electronics technology and it’s extensive laboratory equipment to carry out this work for our client.
https://www.smartpowersolutions.com/wp-content/uploads/2018/09/SiC.jpg781800spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-09-05 09:14:492019-06-08 08:18:253rd SiC MOSFET based project won!!
We have recently made one of our most expensive equipment purchases in order to expand our validation testing capabilities and improve our efficiency. This is a bidirectional (source or sink) power supply that is capable of both AC and DC operation. This 30kVA / 800VDC / 510 V L-L unit also allows single or 3 phase outputs to be generated with huge flexibility in terms of both steady-state and transient waveforms. We have been looking to purchase such a unit for a while and our Technical Partner Dr. Charlie Elliott spent a lot of time researching what was available on the market. In the end we are delighted to say that an independent Spanish company called Cinergia were selected. The unit has clearly been designed by practising power electronics engineers who know exactly what is required on the user interface, communications (Ethernet and CAN) and advanced DSP based controls. The unit has already been used for testing a high efficiency motor drive system. It will also be used for production testing some high energy storage “ultra capacitor” systems in the near future and no doubt plenty of other projects moving forward.
https://www.smartpowersolutions.com/wp-content/uploads/2018/08/Cinergia-1.jpg200200spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-07-10 15:48:572018-08-31 15:54:44More kit for the lab
We are not exhibiting at PCIM this year as PEMD was so close but our Technical Partner (Dr. Charlie Elliott) is going to visit. This key exhibition is a great opportunity to see the very latest in new technologies and meet with many key suppliers. Charlie spends a considerable about of time maintaining our excellent direct links with many power semiconductor, passive component, signal level control, isolation, sensor and ancillary component technology companies. This assists SPS in providing cutting-edge future-proof designs for its customers and also ensures that if any technical issues are identified with components that they can be resolved as rapidly as possible.
We are now back from the PEMD 2018 Conference and Exhibition which was held last week at the ACC in Liverpool. As expected we had warm welcome from the folks on the other side of the Pennines. Liverpool docks is a fantastic area to visit. Well worth a long weekend. The event was well attended and we had plenty of interest in our stand showing the huge diverse range of power electronics we have been involved in.
The papers presented were on a very broad range of topics. For me one of the stand-out areas being looked at by Sheffield University was in the area of using piezoelectric devices as resonant electric transformers at lower powers. A transformer with no windings with power transferred by vibration!! There was also a very interesting tutorial discussion on which of the various power semiconductor technologies is the “best” at 600V. For sure that is an interesting battleground.
We have been big fans of Plexim’s PLECS simulation tool for power electronics for quite some time. We use it across most of our projects for component sizing, controls development and looking at system level behaviour. Our technical partner first came across it many years ago when it was still a free netlist-based basic tool provided by a university. Since then it has been fully commercialised and has come on in leaps and bounds. We have just added another seat of PLECS as we are so busy. This time we have decided to go for the standalone version which doesn’t require Matlab or Simulink. This version also has some additional features which we will no doubt find useful.
https://www.smartpowersolutions.com/wp-content/uploads/2018/05/plecs-logo.png200250spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-04-19 14:52:232018-05-04 14:53:44PLECS – We just added another seat
We are great believers in investing in our lab equipment to make us efficient but always have to keep an eye on costs. Being a modest size outfit ourselves, we are also keen on supporting the small guys out there. When one of our scopes recently failed and it was uneconomic to repair, we therefore had a good look round for what was available from both the big T&M outfits and the smaller independent ones. Not only did we want 4 analogue channels with decent memory depth but also preferably higher resolution than a standard scope and digital logic inputs. At the same time we had been finding that making power switching measurements at high DC voltages was becoming increasingly difficult especially with more modern (faster) transistor technologies. Thus we also wanted something with very low coupling capacitance to earth and preferably isolated inputs, We were amazed to find a unit which met all our requirements by buying the PC based CS448 from NZ based based Cleverscope. Our technical partner was particularly impressed with the care and thought that has gone into the all important front-end of the product and their money back guarantee was the final clincher. The first job the unit was used for was to look at detailed gate drive waveforms on a high power SiC based inverter system. The results were very impressive indeed with very clean waveforms showing the expected “miller effect” waveforms that were previously covered in noise. They even had some custom x200 probes made so we could do power switching waveform measurements at higher DC bus voltages!! No we don’t have any vested interest in those clever chaps in NZ but when you see something you like you should let others know…
https://www.smartpowersolutions.com/wp-content/uploads/2018/05/CS448.jpg361762spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-03-21 16:55:132018-05-08 21:19:20New Isolated Scope for the Lab
As part of our ongoing software quality improvement initiative, our Technical Partner (Charlie Elliott) and one of our Principal Engineers (Mark Berry) are going on a two day training course on MISRA C 2012 next week. This is being run by one of the top software QA tools vendors (LDRA) at their offices in Liverpool and will be presented by members of the MISRA working group. For those of you who are not aware, MISRA C is set of “good practice guidelines” for C and C++ developed by a consortia of (mainly) Automotive engineers . MISRA stands for the Motor Industry Software Reliability Association and was set up to promote good practices within that industry for C/C++ code portability, safety, security and reliability especially within embedded systems. These same guidelines have now been adopted across many industries and as such MISRA C is generally accepted as THE set of guidelines to use on many applications that SPS is involved in.
https://www.smartpowersolutions.com/wp-content/uploads/2018/02/SPS_Logo_Square.jpg24812481spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-03-01 17:14:382018-03-01 20:16:31MISRA C 2012 Training
The week commencing 29th January was a tad busy for our Technical Partner Dr Charlie Elliott!!
Tuesday 30th was the Reinforcing the Grid for the Roll Out of Electrical Vehicles event in London. A very well attended event with interesting and diverse talks. It was particularly interesting to hear from National Grid who think that provided simple charging delay is used so not everybody charges starting at 5-6pm, the increase in demand is very manageable. They think with 150 or so clusters of rapid chargers along key roads (which are often close to the HV grid) a very high percentage of the population will be covered and really range anxiety should become a thing of the past.
Wednesday 31st was the Vehicle To Grid event organised by Cenex and LEVEL in Nottingham. There were a wide range of talks and it was clear that there is still much debate about how people will be able to generate revenue from V2G. One thing is for certain is that it is a great opportunity and that specialist kit available at a sensible price needs to be developed. Watch this space as V2G is a perfect space for SPS given it’s past experience and capabilities!!
Thursday 1st February was the Power Electronics Grand Challenges meeting in Birmingham organised by Innovate UK Knowledge Transfer Network, Power Electronics UK and the Compound Semiconductor Applications Catapult. This meeting was held to discuss direction for potential work with the CSA Catapult and to review whether the 3 grand challenges previously identified with PEUK were still valid. There was much lively debate and the possibility of rolling in the high power requirements for electric powered short haul flights was thrown into the mix. Very interesting times!!!
Charlie commented that it is very clear that new and challenging Power Electronics applications are being identified all the time. Bring it on!!
https://www.smartpowersolutions.com/wp-content/uploads/2018/02/SPS_Logo_Square.jpg24812481spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-02-08 15:46:452018-02-11 20:49:56What a busy week!!
Our Technical Partner, Dr. Charlie Elliott, is attending this fascinating discussion being held in London on the 30th Jan 2018. As SPS is involved in both smart grid and EV charging development it will no doubt be great of great interest. Charlie is looking forward to meeting other professionals within this sector and learning more about this crucial subject.
https://www.smartpowersolutions.com/wp-content/uploads/2018/01/ev-charger-696x529.jpg529696spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-01-21 14:32:332018-01-26 08:44:10Reinforcing the grid for the roll-out of Electric Vehicles
Yesterday we had our ISO9001:2015 external transition audit by BSI. We are delighted to report that we passed with flying colours with no non conformities!! This is a great reflection of the hard work and dedication of our Quality / Production Manager (Alan Yarker) in particular. We are expecting our updated certificate in due course and will update it on the site when we have it. At the same time we are also going to post some of the key aspects from our QMS (scope, policy and objectives) so that you can get a better understanding of our company.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/SPS-bsi-and-ukas400sq-e1603364279501.jpg280400spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-01-12 13:32:202018-01-12 13:32:20Transition to ISO9001:2015 Complete!!
The concept of using EV battery storage as a distributed flexible energy storage system for the grid is not new. It has been talked about for many years. Our technical partner Dr. Charlie Elliott can recall conversations going back almost 10 years. These days it is called Vehicle to Grid and abbreviated to V2G. Charlie, along with Peter Moriarty one of our Principal Engineers, will be going to the Training Workshop on 31st Jan 2018 organised by LEVEL with Cenex. If you are going please call by our table for a chat as this is an area we are very interested in and have exactly the right skill set to develop the technically challenging bi-directional power flow chargers required.
https://www.smartpowersolutions.com/wp-content/uploads/2018/01/ev-charger-696x529.jpg529696spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-01-09 08:50:412018-01-26 08:43:37Vehicle 2 Grid Training Workshop
We have now had our readiness review for ISO9001:2015 with our external auditor from BSI. The outcome of this was very favourable with just a few areas requiring some improvement. This has now been carried out and we are looking forward to our first external audit which is booked for the 11th January 2018.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/SPS-bsi-and-ukas400sq-e1603364279501.jpg280400spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152018-01-03 13:44:182018-01-03 13:44:18Transition to ISO9001:2015 – Update
We are exhibiting at the PEMD2018 Conference which is being held in Liverpool between 17th and 19th April 2018. We will be bringing with us a selection of examples of work we have done in the past which demonstrates the very diverse range of power electronics applications we work on. We are looking forward to also attending the conference which will no doubt have an excellent range of high quality papers. Please call by our stand and have a chat if you are coming.
https://www.smartpowersolutions.com/wp-content/uploads/2017/12/PEMD-2018-logo-e1512386761586-1030x729-1.jpg10641065spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-12-04 11:26:382018-01-24 19:32:01SPS to Exhibit at PEMD2018
We have now completed the first key stage of our transition to ISO9001:2015 by having a full review of our QMS vs this new version of the standard. As a result we have rewritten large sections of our QMS manual and changed some of our procedures. In many areas (especially risk management) we found we were already doing what is required by the new standard but just needed to tighten up on recording. BSI are now booked for 8th December 2017 to carry out a full readiness review and provisionally booked for 11th January 2018 for the first external audit at which we hope to gain certification.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/SPS-bsi-and-ukas400sq-e1603364279501.jpg280400spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-11-11 09:42:112017-11-12 09:43:57Transition to ISO9001:2015
We have recently made a significant investment to upgrade our PCB Layout software (Mentor PADS) to the latest version. This introduces a whole range of new features including significantly enhancing 3D mechanical integration and allowing more complex rules to be defined for meeting electrical safety spacings. This should improve our efficiency in carrying out the challenging designs we have to do which regularly require complex mechanical interaction and also reduces risk as accurate 3D (step) files can be both imported and exported easily. At the same time we have taken the opportunity to improve our parts library to provide better uniformity across projects.
We are delighted to report that two new members of staff have joined SPS as a result of our recent recruitment drive. Both of them have a keen interest and relevant experience in power electronics applications. This is great news for the company as we are so busy. We are still interested in anybody else who would be interested in working with us. Please contact us via the form.
https://www.smartpowersolutions.com/wp-content/uploads/2014/10/team-512.jpg512512spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-08-16 11:52:342017-11-11 18:31:13Two New Members of Staff
In recognition of his technical ability, experience and commercial enterprise, our Technical Partner Dr. Charlie Elliott was recently appointed to be a Fellow of the Institution of Engineering and Technology as reported here.
Charlie commented that although this is a personal achievement that the entire staff at SPS have all made a significant contribution to the success of the business which formed a key part of being eligible for the award. He wanted to pass on his thanks to them.
https://www.smartpowersolutions.com/wp-content/uploads/2017/07/Master-logo.jpg10001000spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-07-18 13:45:302017-12-11 15:01:53Technical Partner appointed FIET
As part of our ongoing training program and commitment to improving quality, our Production and Quality Manager (Alan Yarker) and one of our manufacturing staff (Liz Thewlis) have recently taken the 3 day IPC/WHMA-A 620 Application Specialist course at The Electronics Group just round the ring road from us in Leeds. This intensive 3 day course is aimed at training staff in the Acceptability of Cable and Wire Harness Assemblies. Both Liz and Alan said the course was very worthwhile and passed with no problem. We are very lucky to have such excellent training facilities local to us in Leeds.
https://www.smartpowersolutions.com/wp-content/uploads/2015/07/ipc-logo-1.jpg500500spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-06-22 13:05:192017-11-11 18:20:14IPC/WHMA-A 620 Training and Certification
We are delighted to announce that SPS will be collaborating with one of its longest standing customers Ceres Power Ltd. on a new Innovate UK project for the next 18 months. This is aimed at taking the existing fully-qualified compact power electronics (PE) system for domestic micro CHP and making it production ready for other markets including the Far East. The existing PE unit has been in constant use for 8 years at Ceres Power, including the SteelGen™ units deployed with British Gas in the European funded ene.field programme.
SPS is looking forward to the opportunity to apply the latest technologies to the system as well as gain experience in different geographical markets each of which has their own challenges.
https://www.smartpowersolutions.com/wp-content/uploads/2017/06/IMG-20170613-00144.jpg19442592spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-06-13 11:21:282017-06-13 11:25:09SPS starts major new project
SPS has recently joined two industry bodies which closely reflect the type of work it is involved in. Both are managed and promoted by TechWorks https://nmi.org.uk/techworks-launch/.
AESIN – The Automotive Electronic Systems Innovation Network http://aesin.org.uk/ is a dedicated UK initiative focused on the accelerated and advanced delivery of Electronic Systems into Automotive Applications and infrastructure. This is another perfect fit given the work we do on xEV systems and other intelligent actuator and motor drive systems for automotive applications.
SPS has recently joined two industry bodies which closely reflect the type of work it is involved in. Both are managed and promoted by TechWorks https://nmi.org.uk/techworks-launch/.
Power Electronics UK https://www.power-electronics.org.uk/ has been set up to promote the thriving UK power electronics sector and provide a forum for collaboration. It is a very natural fit for SPS and we are looking forward to being actively involved.
https://www.smartpowersolutions.com/wp-content/uploads/2017/05/PEUK2-1030x515.jpg953952spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-05-05 12:30:582017-12-11 14:53:51SPS Joins Power Electronics UK
Our Technical Partner Dr Charlie Elliott attended the IET PEMD Event at IET Austin Court in Birmingham today. He reported that despite the clash with a couple of other events in related fields it was well attended with very high quality papers presented by both Academia and Industry. The papers can be found here https://communities.theiet.org/communities/files/493
https://www.smartpowersolutions.com/wp-content/uploads/2017/05/pemd-tpn-logo-web.jpg304320spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-04-26 18:17:292017-05-24 06:07:38SPS Attends the IET Machines and Drives for High Speed Applications Event
As a result of a significant increase in customer project activities we are current recruiting. Please see our dedicated page for more details Careers
https://www.smartpowersolutions.com/wp-content/uploads/2015/09/logonews.jpg708708spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-04-20 11:24:442017-05-24 06:08:03We are looking for more engineers to join our team
Our Technical Partner Dr Charlie Elliott attended the relaunch of Power Electronics UK https://www.power-electronics.org.uk in Birmingham today. He reported that the event was well attended and had some great presentations on a diverse range of subjects including not only future Wide Bandgap developments but more immediate industry 4.0 subjects.
https://www.smartpowersolutions.com/wp-content/uploads/2017/05/PEUK2-1030x515.jpg953952spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152017-02-28 18:02:542017-12-11 14:54:48SPS Attends Power Electronics UK Relaunch
We are now back from PCIM 2016 in Nuremberg. This was the first time that SPS had exhibited at the show and it turned out to be very successful for us. We had plenty of interest in our stand and were complemented by many visitors (including a competitor!) on the breadth of our product development experience. Our mix of power electronics and embedded control really impressed people.
https://www.smartpowersolutions.com/wp-content/uploads/2016/05/PCIM_Booth.jpg800600spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152016-05-14 17:03:122016-05-14 17:03:12A very successful PCIM
BSI have now carried out the final stage 2 external audit to ISO9001:2008 and we are delighted to report that we have passed!! This is a fantastic achievement and we are as convinced as ever that this will bring real value to the company and our customers. We have now added a dedicated quality page to our site where you can download our certificate and also find out about our other quality initiatives.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/SPS-bsi-and-ukas400sq-e1603364279501.jpg280400spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152016-02-16 09:45:142016-02-17 17:46:34SPS achieves certification to ISO9001:2008
Zen Production Ltd. have now fully commissioned and installed our vapour phase SMD reflow oven. Since first trialling such an oven in October 2015, Zen kindly loaned SPS their demonstration oven until the model we had selected was available. We have now swapped over to using this and are looking forward to the same high quality results.
We are delighted to report that SPS will be attending the PCIM exhibition in Nuremberg between 10th and 12th May 2016. We will be in booth 6-338 and will be exhibiting both the design and manufacturing sides of the business. PCIM is a unique event and we believe that SPS will be able to demonstrate quite a unusual offering at the show given it covers the full spectrum of both design and manufacturing. SPS is able to take on complex subassembly and even full system builds unlike others companies in the market.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/PCIM.jpg444444spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152016-01-25 12:27:032016-02-17 18:20:56SPS to attend PCIM 2016 Nuremberg
SPS is making great use of its general purpose power conversion controls platform again. This was initially developed as part of a Technology Strategy Board (now Innovate UK) part-funded project in 2009 – with TSB funding this meant the IP was retained by SPS. The controls platform was developed to allow rapid prototyping of systems for customers in the initial proof of concept phase. For the TSB project it allowed SPS to implement a very specific motor control hybrid vehicle requirement. The platform has been invaluable on numerous projects allowing us to use existing building blocks to rapidly prove out initial concepts to customers with low risk and cost. Once the concept is proven, a lower cost targeted implementation can then be developed. The current use is on a 50kW compact static power conversion application.
We are already in the process of revamping this controls platform to take advantage of the latest generation of microcontrollers and to also incorporate additional robustness and flexibility so that it can be used in lower volume niche applications for the manufacturing side of the business. We hope to be able to report on that progress in Q2 16 and publish a full specification.
https://www.smartpowersolutions.com/wp-content/uploads/2015/09/logonews.jpg708708spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-11-23 16:32:322016-02-18 07:48:52SPS Utilises Rapid Prototyping Controls Again
Following on from a positive “pre certification audit”, BSI have now carried out the stage 1 formal external audit to ISO9001:2008 which focuses on the Quality Manual in particular. No non-conformities were found but a few suggestions for improvements have been taken on board and the scope of the QMS expanded to include servicing and maintenance activities.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/BSINews.jpg500500spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-11-10 12:33:312016-02-17 17:24:32BSI carry out ISO9001:2008 stage 1 audit
SPS is trialling an Asscon VP450 small batch vapour phase oven kindly provided by Zen Production Equipment Ltd. (www.zpel.co.uk). We were very impressed by the professional and open approach of Zen both in terms of sales and on-site commissioning support. The very first PCB trialled with the unit was a complex design incorporating significant copper floods with larger SMD components as well as other areas with just signal electronics. Our experienced production technician was very impressed with the excellent quality solder joints that were immediately evident and the simple operation of the machine. As a result of this initial trial and other subsequent successful uses of the machine, the decision was made to go ahead and purchase.
https://www.smartpowersolutions.com/wp-content/uploads/2015/10/vapornews.jpg168168spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-10-12 10:06:342016-02-17 17:27:32SPS Trials Second SMD Reflow Oven
As the next step to achieving ISO9001:2008, SPS have engaged the services of world renowned British Standards Institute (BSI) to carry out a “pre certification” audit of its existing Quality Management System. This was duly carried out with no issues found but just a few suggestions for improvement. These suggestions have been taken on board and minor changes made. BSI have now been fully engaged to carry out stage 1 and stage 2 external auditing with a view to achieving certification in Q1 2016.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/BSINews.jpg500500spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-09-30 11:47:392016-02-17 17:29:18BSI carry out ISO9001:2008 pre-assessment
In anticipation of seeking certification to ISO9001:2008, two SPS staff have attended BSI’s internal auditor course which was held over two days in York. Both Alan Yarker (Production and Quality Manager) and Peter Moriarty (Principal R&D Engineer) found the course to be very helpful in providing a structured approach to auditing. It also allowed them to get some specific key questions answered by people who had clearly been auditing for many years. Having fully trained internal auditors was viewed as being the first key step to achieving certification which is targeted at Q1 16.
https://www.smartpowersolutions.com/wp-content/uploads/2016/02/BSINews.jpg500500spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-09-24 16:23:142016-02-18 08:28:33ISO9001:2008 Internal Auditor Training
Having our own internal capability for high quality assembly of SMD PCBs for prototyping and small manufacturing batch runs has always been essential to meet customer lead times. Without a large multi-zone heater reflow oven and the possibility of tweaking parameters to optimise production yield, this is not a straightforward task. This has been compounded by the move to lead-free soldering and the same PCB having a large range of size and weight of components and tracking / flooding. Historically a modest size convection reflow oven has been used by SPS but it was apparent that a higher performance oven would be required for future use. An internal review of different reflow technologies was carried out by our production department and advice sought from various suppliers. After poor results from trialling a popular oven specifically designed for low volume / batch work, advice was sought from Electronics Yorkshire. They recommended using vapour phase technology which SPS was familiar with as a technology as it has been used for many years for soldering copper base plates to the underside of the DBC in isolated power modules.
https://www.smartpowersolutions.com/wp-content/uploads/2015/09/logonews.jpg708708spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152015-09-21 14:03:322016-02-17 16:29:31Review of in-house SMD Soldering
We are fortunate in having a very experienced production technician (Elizabeth Thewlis) who joined SPS in June 2012 having previously worked for many years in the power electronics industry. Liz had previously been trained to IPC-A-610 but her certification had lapsed. Given her experience it was an obvious decision to ask her to take the IPC-A-610 certified instructor course at Electronics Yorkshire so she could then instruct other members of staff. She duly completed the course in July 2015.
As a result of a significant increase in both manufacturing and development work, SPS has taken on another full time engineer. Kyriakos Papameletis (Kyri) recently completed his Master’s degree at Leeds University in “Electrical Engineering and Renewable Energy Systems”. He will be assisting with supporting test and debug work in manufacturing as well as development work on the design side of the business. This means that we now have 7 Engineers on the development side of the business who all studied at Leeds University and between us we have 3 PhD.s, 3 Masters and 5 Bachelor Degrees!! Two of us are also Chartered Engineers – the equivalent of P.E for our North American colleagues.
https://www.smartpowersolutions.com/wp-content/uploads/2014/10/team-512.jpg512512spssps15https://www.smartpowersolutions.com/wp-content/uploads/2015/05/0717-SMA-Logo-ALL-tx-WEB-2500x111.pngspssps152014-10-06 11:04:132016-02-18 08:06:30New Member of the Team
After a 1 month trial, SPS has gone ahead with purchasing a combined frequency response and wide bandwidth impedance analyser (PSM1735 + IAI fixture) manufactured by UK company Newton’s 4th Limited. Having access to this piece of equipment will allow more accurate and reliable characterisation of the frequency response of the significant range of complex control systems that SPS develops.
The previous piece of equipment SPS used for this was limited in its ability and was reaching the end of its life. The Impedance Analysis Interface module will also assist SPS with assessing the performance of both standard and custom designed components all the way up to 35 MHz which is an essential part of switched-mode power conversion and Electromagnetic Compatibility development work.
LCV2021 – We are on stand C4-307
/in Events /by spssps15LCV2020 – Update
/in Uncategorised /by spssps15We are very excited to be involved in LCV2020 as an exhibitor. Looks like the virtual booth doesnt have a web chat which comes as a surprise. For today please use the MS Teams link here if you want to video chat with our technical partner Dr Charlie Elliott. We will post another one tomorrow.
Join Microsoft Teams Meeting
LCV2020 – Online exhibition
/in Events /by spssps15We are delighted to announce that we be participating in the online version of LCV on 18th and 19th November 2020 . It is a great shame that this well attended and fantastic event can’t happen physically this year. However we have a virtual booth to give you a better feel for the advanced motor-drives and other power conversion equipment we can design and manufacture. Please do come and visit and have a virtual chat. We will also be launching the first of our own products for EV charging installation protection via our suster company Smart Power Products. Lots more to come on that.
Innovate UK Grant Application
/in Events /by spssps15Our Technical Partner (Dr Charlie Elliott) had a busy end to last week getting in a grant application to Innovate UK. It is great to see that UK Gov / IUK has responded rapidly to the current crisis. It is running a short turn-around 100% funded grant scheme for up to £50k to be spent within 6 months. SPS has applied to allow it to design an innovative power electronics controller for use a wide variety of applications. The grant will cover the hardware design and prototyping.
SPS gets many enquiries where the volumes don’t justify a fully custom solution. Using a common controller but with bespoke power electronics is a very useful half-way house. It should allow SPS to win more projects and thereby sustain it going forward and hopefully expand!! The controller will support many different applications but will be principally aimed at niche vehicle electrification projects such as emergency vehicles, rail works trains, construction and mining equipment. The hardware and software will support not only motor drives but also ACDC and DCDC power conversion requirements.
If we are granted the funding, we will be kicking the project off in about 4 weeks times. We anticipate having the controller ready for use by the end of 2020. If you think this is of interest to you then please do make contact and we can give you more information in terms of specification and cost targets.
COVID-19 Update
/in Events /by spssps15SPS continues to function as effectively as possible during these challenging times in order to support our staff, customers and economy. The safety of our staff is of course paramount. As requested by UK government, where possible they are working from home. All staff have access to all their normal design tools and resources. Please use e-mail as first means of contact.
Where manufacturing or test/validation work is involved, staff will be in work. We have plenty of space so can easily meet the 2m safe “social distancing” advice. We have also taken additional steps to minimise risk as best as possible in terms of delivery hygiene and additional cleaning etc.
The partners of SPS would like to reassure its customers (and prospective ones) that the business is in a good position to weather this storm both in terms of its finances and its logistics. We have been in contact with our key suppliers and in the vast majority of cases they working although with slightly increased lead-times.
Be safe everybody and let’s hope that some positives can come out of this!!
Motor Drive Development – Still innovative after 20 years!!
/in Facilities, Qualifications /by spssps15Recently our Commercial Partner (Ms Patricia Elliott B.Eng) was kindly given an item by the company she used to work for (Nidec SR Drives Ltd.). It was the last product she worked on before she left to set up Smart Power Solutions with our Technical Partner (Dr. Charlie Elliott). It is a high-power commercial vacuum cleaner unit used in larger homes and hotels in the US.
In order to keep size down and allow for long-life, a high-speed 2-phase Switched Reluctance Motor was used. To minimise input current whilst keeping cost low, a valley-fill power-factor improvement circuit was used. The control was implemented in a sub $1 microcontroller. As far as we are aware, nobody else has ever implemented such an innovative motor drive for this application since. When it was powered up in our lab, it worked after being sat in storage for almost 20 years!!
SPS is very well positioned to carry out motor drive development on all conceivable motor types. It has experience from low power 20W fans all the way up to 1MW mining applications. You won’t be surprised to hear that SPS is heavily involved in electrification of transport projects for both on and off-road use.
Innovative Motor Drive
Visit to Dynex
/in Events /by spssps15Our Technical Partner Dr. Charlie Elliott visited Dynex in Lincoln yesterday. As well as a general catch up he wanted to discuss possible technical collaboration utilisting SPS’s experience with power electronics systems development. Charlie first came across Dynex when they were GEC Plessy Semiconductors as a graduate trainee at GEC Electrial Projects in 1991. It is about 15 years since he last visited and he reported that is was great to see them thriving with investment from majority Chinese owners CRRC. Not only are they busy with manufacturing their existing range of power semiconductors, but they are pushing hard to improve them.
Their power assemblies unit is continuing with its excellent reputation for supplying specialist traction refurbishment and other high power applications. It operates at power levels well above what SPS can manufacture so there is no real overlap. SPS is hoping it can complement what Dynex already does and assist with power electronics systems when their customers are looking for this capability.
SPS is developing it’s own products!!
/in Events /by spssps15During the 18 years SPS has been in business, it has developed a hugely diverse range of products for its customers. These have covered mW to MW (careful with the capitalisation!!) in areas such as Medical, Automotive, White Goods, Oil & Gas, Railways and Industrial. All of them have a general theme of using electronics to control power and ususally with software. SPS has a very straightforward commercial model with respect to the design rights – if you pay for it you own it!! In all cases to date, our customers have chosen to own the design.
Over the years we have seen a few niche opportunities that we have wondered whether we should exploit independently. We believe now is the time to do this but of course being careful not to compete with our customers and making sure we still have enough resource to properly look after them. We will be initially focusing on products we can manufacture ourselves but also looking at designs we could licence or subcontract if volumes are higher.
When we are further down the road with these in-house products, we will be publishing some details and looking for early adopters. Meanwhile, if you can think of a niche power related product that you can see a need for then please do get in contact.
SPS awarded Premier Design Partner Status Again
/in Qualifications /by spssps15We are delighted to be able to report that SPS has yet again been awarded the status of Premier Design Partner by Microchip Technology. We use their parts (mainly 16 bit dsPICs + analogue parts) on the majority of the work we carry out due to the excellent performance, choice, cost and availability of their parts. Being a Premium Partner also means we get priority technical support and advance notification of new parts and technology. Both of these things are very important to provide the best possible service to our customers. Not wishing to be big headed, but SPS is the only Premier Design Partner with Motor Control Expertise in Europe and the only one worldwide with this ranking for both Motor Control and Functional Safety.
Visit by key supplier – ST to discuss SiC and other things.
/in Events /by spssps15Our Technical Partner Dr Charlie Elliott had a very fruitful discussion with a key supplier (ST) this morning. This was to mainly discuss a new automotive EV inverter enquiry but to also get an update on all sorts of things. Charlie caught up with Keith D’Souza who he has known for well over 15 years. It turns out that on Friday Keith will have been with ST for 30 years. Many congratulation to you Keith!!
Charlie spends a fair bit of time ensuring that SPS maintains it’s excellent direct links with key component suppliers and makes sure they stay up to date with latest technology trends and product offerings.
Compound Semiconductor Application Catapult Visit
/in Events /by spssps15Our Technical Partner (Dr. Charlie Elliott) visited the Compound Semiconductor Application Catapult in Newport last week. He commented that is was great to see the fantastic team and facilities that are rapidly being established there. We are very much looking forward to working with them on future projects and already have a perfect application that could involve them for high voltage and high power (muti-MW) systems.
High torque motor drive system testing
/in Events /by spssps15Two of our Principal Engineers have just come back from being on site at Newcastle University School of Electronic and Electrical Engineering. They were utilising the excellent dynamometer facilities that are installed there. The motor under test was a high pole-count (66!) permanent magnet type which is controlled by a bespoke high-reliability and rugged inverter SPS designed and manufactured for its client. The high torque (1800Nm) system performed very well and pushed the dyno well above where it had ever previously been used since it was installed.
In the new year SPS will be working on updating the software and control interface for the end application and then going on-site with our customer to test the system in the final application.
Traction Power Converters Shipped
/in Uncategorised /by spssps15SPS has just completed supplying the first batch of traction power converters used by Clayton Equipment in their innovative full-electric and hybrid locomotives. They are rated at up to 180 kW and suitable for use at up to 750 V DC (max) with IP68 rating. Specific steps have been taken with the design to ensure high reliability with the inevitable power cycling such units experience in operation.
Unusually, these are air-cooled to provide packaging flexibility and improve reliability vs a liquid cooled approach. The fans maintain the IP68 rating and give several years of life before servicing is required. The converters can be supplied liquid cooled if required.
SPS is very well placed to both design and manufacture specialist power conversion equipment for lower-volume demanding applications. Please contact us if this is something you are interested in.
Succesful External ISO9001 Audit
/in Events, Qualifications /by spssps15Today was our annual external audit by BSI for our ISO9001:2015 quality management system. I am pleased to report that we passed with flying colours with no non-conformities at all. We did have an interesting discussion with our auditor on the subject of collaborative working. For certain this is the manner in which we prefer to work with our customers as it benefits both parties. He kindly told us about the Institute of Collaborative Working and the fact there is a specific standard and accredition (ISO 44001:2017) available. Perhaps something to consider for the future!! Meanwhile our training program will continue to make sure out staff have the relevent skills required.
EV SiC-based Inverter Project Update
/in Events, Facilities, Qualifications /by spssps15SPS has just started testing the latest version of the highly challenging PCB it has designed for an automotive SiC-based EV inverter. The PCB not only implements all the required gate drive but integrates many other essential sensing and other auxiliary features to ensure electrical and functional safety. The space available for the PCB is very tight, the DC voltage high (up to 900V) and it has to press-fit to a power module where all the connection locationss are already set. The combined effect of this is that it has really challenged our most experienced PCB layout designer who has 25+ years experience.
The entire development of the PCB has been done in-house including the validation testing and manufacture of prototype PCBs. Given SPS’s senior staff have been working on xEV systems for well over 20 years, it is not surprising that our end customer has also asked us to assist with many other areas of their development. This includes advice on electrical / functional safety, EMC mitigation measures and thermal management. SPS has also carried out critical testing of the inverter system including full double pulse switch testing over the entire range of voltages, current and temperatures. This is an essential aspect of power electronics development that is unfortunately either skipped entirely or not done thoroughly by many other companies. This can result in an unacceptable amount of unknown risk in a product leading to reliability problems in the field. Most certainly not an option for an automtive product!! Please do contact us if our facilities and experience could be of use to your company.
Innovate UK Project a Success!!
/in Uncategorised /by spssps15SPS has now completed the IUK funded project with it’s long term customer Ceres Power that began in July 2017. SPS’s part of the project was associated with a low-cost 1kW isolated DC to AC grid tied inverter system for use on Fuel Cell based micro combined heat and power residential applications. SPS’s two main objectives for the project were:
We are delighted to report that using one of our calibrated digital power meters, the efficiency was measured at 92.1% once the unit had reached its final temperature. This efficiency was achieved using low-cost silicon power semiconductor technology rather than using the latest “Wide-bandgap” devices. The latter is too expensive for the target application at this point in time. However, the new design is flexible enough to be upgraded with minimal effort when this situation changes in the future. Efficiencies of more like 95% will then be achievable.
SPS is now looking to exploit what it has learned through this project both from the core power electronics and the grid connectivity requirements. Please do get in contact if this is of interest. A photo of one of the prototypes that were produced in house is shown below.
Functional Safety
/in Qualifications /by spssps15The control of electrical power is fundamental to what SPS does and has inevitable safety implications not just in its raw form but also in terms of what it allows you to do to effect motion etc. It is something that SPS takes very seriously in all aspects of what it does to protect its staff, customers and end users. This is epecially so in certain sectors such as automotive, medical, railways and industrial where over the years formal functional safety standards have evolved.
SPS has recently been officially recognised by Microchip as having sufficient experience in this area to become one of select few functional safety design partners. SPS uses Microchip products to implement all of its embedded control partly as they have products with the required features and tools/libraries available to aid meeting safety requirements. A summary of their capabilities can be found here.
We will be continuing to expand our expertise in this area by investing in training and the relevant processes and software tools especially with respect to software development and testing.
June is Training Month at SPS
/in Qualifications /by spssps15Not quite sure why it has worked out like this but June seems to be the month for Training this year. First of all one of our Principal Engineers (Peter Moriarty) went on a 4 day course run by Ridley Engineering on Power Supply Design. This is a world reneowned course run by one of the leaders in the SMPS industry which is both theoretical and hands on.
Next our production staff are renewing their IPC qulifications in IPC A-610 – Acceptability of Electronic Assemblies and IPC WHMA-A-620 – Requirements and Acceptance for Cable and Wire Harness Assemblies
All of staff have a target of doing at least 1 day training a year. Sometimes this is in the form of internal mentoring but where possible we try to find external courses so we can expand our knowledge within the company. This is one of our stated QMS objectives.
PCIM 2019
/in Events /by spssps15May in Nuremberg – must be time for PCIM again!! This year as well as our Technical Partner Dr. Charlie Elliott, our Production and Quality Manager Alan Yarker also attended. Sadly no sitting outside drinking cold beers this year and thanks to KLM it was a bit of a truncated visit but still well worth while. Very good to see there is more than just marketing hype to the introduction of Wide Band Gap semiconductors. Very notable increase in the number of major players with physical parts now in modules. Availability and cost are still major issues but things are improving on both fronts. It was great to catch up with many of our key suppliers, find a new one or two and even chat with competitors. PCIM is still the go to event as far as we can see. Can’t say we have ever been to APEC but am seriously considering it for next year.
Stephenson Challenge / Driving the Electric Revolution
/in Events /by spssps15Our Technical Partner Dr. Charlie Elliot has been involved in this cross industry initiative for quite some time as it originated in Power Electronics UK. He recently attended a key update meeting in Birmingham. A detailed video giving more details can be found here. Subject to business case and match funding from industry, government has announced that it is prepared to invest up to £78 million in this challenge. This will be managed through Innovate UK and the Industrial Strategy Challenge Fund – wave 3.
The challenge is all about developping a UK supply chain for power electronics machines and drives across 7 industrial sectors. All 7 sectors are cruicial if we are to hit our future emmissions targets whilst mainting or exceeding the standard of life we are all used to. We will be keeping a close eye as things develop as this major initiative is something SPS would very much like to be part of and is very well placed both in terms of experience and facilities.
Second V2G Workshop
/in Events /by spssps15Our Technical Partner Dr Charlie Elliott attended the second Cenex / Level Vehicle to Grid (V2G) workshop held in Nottingham on 6th February. It was a follow on event from the one in 2018 and it was great to see presentations on the outcome from real world installations abroad and in the UK. As last year there was some healthy debate as to the real world commercial feasibility of V2G in the UK. In other countries certain markets for services have artifically high prices which makes V2G a much simpler proposition.
Courtesy of a £30M Innovate UK funded project there is a lot of activity in this area at the moment which is great to see but also a bit frustrating for a UK based power electronics design and manufacturing company not even contacted to be involved!! One project in particular promises to install up to 1k V2G systems for domestic use. Sadly the core power electronics of this and other systems within the IUK project are being bought in from abroad presumably as there was thought to be insufficient time/budget/knowledge to carry out the development in the UK. Driving down the price of the hardware for V2G is essential to make it commercially viable. SPS is exceptionally well-placed to carry out such work given its existing experience in bidirectional grid-tied inverters and DCDC converters built up over many years. It has also previously worked on DC rapid chargers for EVs. SPS is currently investigating sources of funding / partners for such activity. If you are interested then please do get in contact.
Another sucessful project delivered!!
/in Events /by spssps15Our Technical Partner Dr. Charlie Elliott has just come back from Brazil where he sucessfully commissioned an ultra-compact high-efficiency motor-drive inverter based on SiC MOSFETs. This 15kW system hit 98% efficiency which is fairly special in it’s own right. If you then add the fact that the system has to work at 330 bar pressure on the bottom of the sea bed then you probably have a world first!! Charlie was testing the system flooded with pressure compensating oil in a special test chamber in Rio de Janeiro.
External ISO9001:2015 Audit Success
/in Qualifications /by spssps15We had our first external audit of our ISO9001:2015 QMS by BSI since we made the 2008-2015 transition yesterday. I am pleased to announce that we passed with no issues at all, not even a minor non-conformance. Well done to all involved. Two “Opportunities for Improvement” were made that we will be taking on board in due course. We will publish the new certificate when it comes available on our quality page.
LCV 2018
/in Events /by spssps15Out Technical Partner Dr. Charlie Elliott decided to get in the spirit of things and take his own 30kWh Nissan Leaf to LCV this year. It wasn’t just for the free parking (although he has been in Yorkshire for over 30 years so something must have rubbed off by now) but also as a bit of a show of solidarity. Two stops for 20 mins each on the way there and back to rapid charge was no issue at all with a coffee and a few e-mails written each time. Charging was free at the event and he even made use of the measured mile at Milbrook to see how the leaf did – a ton wasnt a problem! He reported that LCV has grown again and it was great to see so many UK based outfits working hard in the Low Carbon Vehicle sector. We may have to think about taking a stand next year.
3rd SiC MOSFET based project won!!
/in Events /by spssps15We are delighted to report that we have just kicked off another significant project using SiC MOSFETs. In the past 18 months we have been working on two SiC based motor drive systems. One is for an EV project where the attraction of SiC is the power density and part load efficiency benefits. The latter in particular is essential as it offers potential for reduction in battery pack capacity/size/cost or alternatively additional range. The other existing project is for an ultra high-efficiency motor drive where size is especially important and cost less so.
This new project is for higher power 500 kVA static-power conversion system where being able to switch at 20 kHz and above is essential to reduce the size of filtering components and eliminate switching frequency audible noise. Up at these kinds of power / current levels there is no choice but to parallel commercially available power modules. This brings it’s own challenges in terms of gate drive function and power circuit layout to ensure sharing of losses and to eliminate the potential for the modules to oscillate against each other. SPS will be using it’s wealth of experience in core power electronics technology and it’s extensive laboratory equipment to carry out this work for our client.
More kit for the lab
/in Facilities /by spssps15We have recently made one of our most expensive equipment purchases in order to expand our validation testing capabilities and improve our efficiency. This is a bidirectional (source or sink) power supply that is capable of both AC and DC operation. This 30kVA / 800VDC / 510 V L-L unit also allows single or 3 phase outputs to be generated with huge flexibility in terms of both steady-state and transient waveforms. We have been looking to purchase such a unit for a while and our Technical Partner Dr. Charlie Elliott spent a lot of time researching what was available on the market. In the end we are delighted to say that an independent Spanish company called Cinergia were selected. The unit has clearly been designed by practising power electronics engineers who know exactly what is required on the user interface, communications (Ethernet and CAN) and advanced DSP based controls. The unit has already been used for testing a high efficiency motor drive system. It will also be used for production testing some high energy storage “ultra capacitor” systems in the near future and no doubt plenty of other projects moving forward.
PCIM 2018
/in Events /by spssps15We are not exhibiting at PCIM this year as PEMD was so close but our Technical Partner (Dr. Charlie Elliott) is going to visit. This key exhibition is a great opportunity to see the very latest in new technologies and meet with many key suppliers. Charlie spends a considerable about of time maintaining our excellent direct links with many power semiconductor, passive component, signal level control, isolation, sensor and ancillary component technology companies. This assists SPS in providing cutting-edge future-proof designs for its customers and also ensures that if any technical issues are identified with components that they can be resolved as rapidly as possible.
PEMD 2018
/in Events /by spssps15We are now back from the PEMD 2018 Conference and Exhibition which was held last week at the ACC in Liverpool. As expected we had warm welcome from the folks on the other side of the Pennines. Liverpool docks is a fantastic area to visit. Well worth a long weekend. The event was well attended and we had plenty of interest in our stand showing the huge diverse range of power electronics we have been involved in.
The papers presented were on a very broad range of topics. For me one of the stand-out areas being looked at by Sheffield University was in the area of using piezoelectric devices as resonant electric transformers at lower powers. A transformer with no windings with power transferred by vibration!! There was also a very interesting tutorial discussion on which of the various power semiconductor technologies is the “best” at 600V. For sure that is an interesting battleground.
PLECS – We just added another seat
/in Facilities /by spssps15We have been big fans of Plexim’s PLECS simulation tool for power electronics for quite some time. We use it across most of our projects for component sizing, controls development and looking at system level behaviour. Our technical partner first came across it many years ago when it was still a free netlist-based basic tool provided by a university. Since then it has been fully commercialised and has come on in leaps and bounds. We have just added another seat of PLECS as we are so busy. This time we have decided to go for the standalone version which doesn’t require Matlab or Simulink. This version also has some additional features which we will no doubt find useful.
New Isolated Scope for the Lab
/in Facilities /by spssps15We are great believers in investing in our lab equipment to make us efficient but always have to keep an eye on costs. Being a modest size outfit ourselves, we are also keen on supporting the small guys out there. When one of our scopes recently failed and it was uneconomic to repair, we therefore had a good look round for what was available from both the big T&M outfits and the smaller independent ones. Not only did we want 4 analogue channels with decent memory depth but also preferably higher resolution than a standard scope and digital logic inputs. At the same time we had been finding that making power switching measurements at high DC voltages was becoming increasingly difficult especially with more modern (faster) transistor technologies. Thus we also wanted something with very low coupling capacitance to earth and preferably isolated inputs, We were amazed to find a unit which met all our requirements by buying the PC based CS448 from NZ based based Cleverscope. Our technical partner was particularly impressed with the care and thought that has gone into the all important front-end of the product and their money back guarantee was the final clincher. The first job the unit was used for was to look at detailed gate drive waveforms on a high power SiC based inverter system. The results were very impressive indeed with very clean waveforms showing the expected “miller effect” waveforms that were previously covered in noise. They even had some custom x200 probes made so we could do power switching waveform measurements at higher DC bus voltages!! No we don’t have any vested interest in those clever chaps in NZ but when you see something you like you should let others know…
MISRA C 2012 Training
/in Qualifications /by spssps15As part of our ongoing software quality improvement initiative, our Technical Partner (Charlie Elliott) and one of our Principal Engineers (Mark Berry) are going on a two day training course on MISRA C 2012 next week. This is being run by one of the top software QA tools vendors (LDRA) at their offices in Liverpool and will be presented by members of the MISRA working group. For those of you who are not aware, MISRA C is set of “good practice guidelines” for C and C++ developed by a consortia of (mainly) Automotive engineers . MISRA stands for the Motor Industry Software Reliability Association and was set up to promote good practices within that industry for C/C++ code portability, safety, security and reliability especially within embedded systems. These same guidelines have now been adopted across many industries and as such MISRA C is generally accepted as THE set of guidelines to use on many applications that SPS is involved in.
What a busy week!!
/in Events /by spssps15The week commencing 29th January was a tad busy for our Technical Partner Dr Charlie Elliott!!
Tuesday 30th was the Reinforcing the Grid for the Roll Out of Electrical Vehicles event in London. A very well attended event with interesting and diverse talks. It was particularly interesting to hear from National Grid who think that provided simple charging delay is used so not everybody charges starting at 5-6pm, the increase in demand is very manageable. They think with 150 or so clusters of rapid chargers along key roads (which are often close to the HV grid) a very high percentage of the population will be covered and really range anxiety should become a thing of the past.
Wednesday 31st was the Vehicle To Grid event organised by Cenex and LEVEL in Nottingham. There were a wide range of talks and it was clear that there is still much debate about how people will be able to generate revenue from V2G. One thing is for certain is that it is a great opportunity and that specialist kit available at a sensible price needs to be developed. Watch this space as V2G is a perfect space for SPS given it’s past experience and capabilities!!
Thursday 1st February was the Power Electronics Grand Challenges meeting in Birmingham organised by Innovate UK Knowledge Transfer Network, Power Electronics UK and the Compound Semiconductor Applications Catapult. This meeting was held to discuss direction for potential work with the CSA Catapult and to review whether the 3 grand challenges previously identified with PEUK were still valid. There was much lively debate and the possibility of rolling in the high power requirements for electric powered short haul flights was thrown into the mix. Very interesting times!!!
Charlie commented that it is very clear that new and challenging Power Electronics applications are being identified all the time. Bring it on!!
Reinforcing the grid for the roll-out of Electric Vehicles
/in Events /by spssps15Our Technical Partner, Dr. Charlie Elliott, is attending this fascinating discussion being held in London on the 30th Jan 2018. As SPS is involved in both smart grid and EV charging development it will no doubt be great of great interest. Charlie is looking forward to meeting other professionals within this sector and learning more about this crucial subject.
Transition to ISO9001:2015 Complete!!
/in Qualifications /by spssps15Yesterday we had our ISO9001:2015 external transition audit by BSI. We are delighted to report that we passed with flying colours with no non conformities!! This is a great reflection of the hard work and dedication of our Quality / Production Manager (Alan Yarker) in particular. We are expecting our updated certificate in due course and will update it on the site when we have it. At the same time we are also going to post some of the key aspects from our QMS (scope, policy and objectives) so that you can get a better understanding of our company.
Vehicle 2 Grid Training Workshop
/in Events /by spssps15The concept of using EV battery storage as a distributed flexible energy storage system for the grid is not new. It has been talked about for many years. Our technical partner Dr. Charlie Elliott can recall conversations going back almost 10 years. These days it is called Vehicle to Grid and abbreviated to V2G. Charlie, along with Peter Moriarty one of our Principal Engineers, will be going to the Training Workshop on 31st Jan 2018 organised by LEVEL with Cenex. If you are going please call by our table for a chat as this is an area we are very interested in and have exactly the right skill set to develop the technically challenging bi-directional power flow chargers required.
Transition to ISO9001:2015 – Update
/in Qualifications /by spssps15We have now had our readiness review for ISO9001:2015 with our external auditor from BSI. The outcome of this was very favourable with just a few areas requiring some improvement. This has now been carried out and we are looking forward to our first external audit which is booked for the 11th January 2018.
SPS to Exhibit at PEMD2018
/in Events /by spssps15We are exhibiting at the PEMD2018 Conference which is being held in Liverpool between 17th and 19th April 2018. We will be bringing with us a selection of examples of work we have done in the past which demonstrates the very diverse range of power electronics applications we work on. We are looking forward to also attending the conference which will no doubt have an excellent range of high quality papers. Please call by our stand and have a chat if you are coming.
Transition to ISO9001:2015
/in Qualifications /by spssps15We have now completed the first key stage of our transition to ISO9001:2015 by having a full review of our QMS vs this new version of the standard. As a result we have rewritten large sections of our QMS manual and changed some of our procedures. In many areas (especially risk management) we found we were already doing what is required by the new standard but just needed to tighten up on recording. BSI are now booked for 8th December 2017 to carry out a full readiness review and provisionally booked for 11th January 2018 for the first external audit at which we hope to gain certification.
PCB Design Software Upgrade
/in Facilities /by spssps15We have recently made a significant investment to upgrade our PCB Layout software (Mentor PADS) to the latest version. This introduces a whole range of new features including significantly enhancing 3D mechanical integration and allowing more complex rules to be defined for meeting electrical safety spacings. This should improve our efficiency in carrying out the challenging designs we have to do which regularly require complex mechanical interaction and also reduces risk as accurate 3D (step) files can be both imported and exported easily. At the same time we have taken the opportunity to improve our parts library to provide better uniformity across projects.
Two New Members of Staff
/in Facilities /by spssps15We are delighted to report that two new members of staff have joined SPS as a result of our recent recruitment drive. Both of them have a keen interest and relevant experience in power electronics applications. This is great news for the company as we are so busy. We are still interested in anybody else who would be interested in working with us. Please contact us via the form.
Technical Partner appointed FIET
/in Qualifications /by spssps15In recognition of his technical ability, experience and commercial enterprise, our Technical Partner Dr. Charlie Elliott was recently appointed to be a Fellow of the Institution of Engineering and Technology as reported here.
Charlie commented that although this is a personal achievement that the entire staff at SPS have all made a significant contribution to the success of the business which formed a key part of being eligible for the award. He wanted to pass on his thanks to them.
IPC/WHMA-A 620 Training and Certification
/in Qualifications /by spssps15As part of our ongoing training program and commitment to improving quality, our Production and Quality Manager (Alan Yarker) and one of our manufacturing staff (Liz Thewlis) have recently taken the 3 day IPC/WHMA-A 620 Application Specialist course at The Electronics Group just round the ring road from us in Leeds. This intensive 3 day course is aimed at training staff in the Acceptability of Cable and Wire Harness Assemblies. Both Liz and Alan said the course was very worthwhile and passed with no problem. We are very lucky to have such excellent training facilities local to us in Leeds.
SPS starts major new project
/in Events /by spssps15We are delighted to announce that SPS will be collaborating with one of its longest standing customers Ceres Power Ltd. on a new Innovate UK project for the next 18 months. This is aimed at taking the existing fully-qualified compact power electronics (PE) system for domestic micro CHP and making it production ready for other markets including the Far East. The existing PE unit has been in constant use for 8 years at Ceres Power, including the SteelGen™ units deployed with British Gas in the European funded ene.field programme.
SPS is looking forward to the opportunity to apply the latest technologies to the system as well as gain experience in different geographical markets each of which has their own challenges.
SPS Joins AESIN
/in Events /by spssps15SPS has recently joined two industry bodies which closely reflect the type of work it is involved in. Both are managed and promoted by TechWorks https://nmi.org.uk/techworks-launch/.
AESIN – The Automotive Electronic Systems Innovation Network http://aesin.org.uk/ is a dedicated UK initiative focused on the accelerated and advanced delivery of Electronic Systems into Automotive Applications and infrastructure. This is another perfect fit given the work we do on xEV systems and other intelligent actuator and motor drive systems for automotive applications.
SPS Joins Power Electronics UK
/in Events /by spssps15SPS has recently joined two industry bodies which closely reflect the type of work it is involved in. Both are managed and promoted by TechWorks https://nmi.org.uk/techworks-launch/.
Power Electronics UK https://www.power-electronics.org.uk/ has been set up to promote the thriving UK power electronics sector and provide a forum for collaboration. It is a very natural fit for SPS and we are looking forward to being actively involved.
SPS Attends the IET Machines and Drives for High Speed Applications Event
/in Events /by spssps15Our Technical Partner Dr Charlie Elliott attended the IET PEMD Event at IET Austin Court in Birmingham today. He reported that despite the clash with a couple of other events in related fields it was well attended with very high quality papers presented by both Academia and Industry. The papers can be found here https://communities.theiet.org/communities/files/493
We are looking for more engineers to join our team
/in Facilities /by spssps15As a result of a significant increase in customer project activities we are current recruiting. Please see our dedicated page for more details Careers
SPS Attends Power Electronics UK Relaunch
/in Events /by spssps15Our Technical Partner Dr Charlie Elliott attended the relaunch of Power Electronics UK https://www.power-electronics.org.uk in Birmingham today. He reported that the event was well attended and had some great presentations on a diverse range of subjects including not only future Wide Bandgap developments but more immediate industry 4.0 subjects.
A very successful PCIM
/in Events /by spssps15We are now back from PCIM 2016 in Nuremberg. This was the first time that SPS had exhibited at the show and it turned out to be very successful for us. We had plenty of interest in our stand and were complemented by many visitors (including a competitor!) on the breadth of our product development experience. Our mix of power electronics and embedded control really impressed people.
SPS achieves certification to ISO9001:2008
/in Qualifications /by spssps15BSI have now carried out the final stage 2 external audit to ISO9001:2008 and we are delighted to report that we have passed!! This is a fantastic achievement and we are as convinced as ever that this will bring real value to the company and our customers. We have now added a dedicated quality page to our site where you can download our certificate and also find out about our other quality initiatives.
Vapour Phase Reflow Oven Commissioned
/in Facilities /by spssps15Zen Production Ltd. have now fully commissioned and installed our vapour phase SMD reflow oven. Since first trialling such an oven in October 2015, Zen kindly loaned SPS their demonstration oven until the model we had selected was available. We have now swapped over to using this and are looking forward to the same high quality results.
SPS to attend PCIM 2016 Nuremberg
/in Events /by spssps15We are delighted to report that SPS will be attending the PCIM exhibition in Nuremberg between 10th and 12th May 2016. We will be in booth 6-338 and will be exhibiting both the design and manufacturing sides of the business. PCIM is a unique event and we believe that SPS will be able to demonstrate quite a unusual offering at the show given it covers the full spectrum of both design and manufacturing. SPS is able to take on complex subassembly and even full system builds unlike others companies in the market.
SPS Utilises Rapid Prototyping Controls Again
/in Facilities /by spssps15SPS is making great use of its general purpose power conversion controls platform again. This was initially developed as part of a Technology Strategy Board (now Innovate UK) part-funded project in 2009 – with TSB funding this meant the IP was retained by SPS. The controls platform was developed to allow rapid prototyping of systems for customers in the initial proof of concept phase. For the TSB project it allowed SPS to implement a very specific motor control hybrid vehicle requirement. The platform has been invaluable on numerous projects allowing us to use existing building blocks to rapidly prove out initial concepts to customers with low risk and cost. Once the concept is proven, a lower cost targeted implementation can then be developed. The current use is on a 50kW compact static power conversion application.
We are already in the process of revamping this controls platform to take advantage of the latest generation of microcontrollers and to also incorporate additional robustness and flexibility so that it can be used in lower volume niche applications for the manufacturing side of the business. We hope to be able to report on that progress in Q2 16 and publish a full specification.
BSI carry out ISO9001:2008 stage 1 audit
/in Qualifications /by spssps15Following on from a positive “pre certification audit”, BSI have now carried out the stage 1 formal external audit to ISO9001:2008 which focuses on the Quality Manual in particular. No non-conformities were found but a few suggestions for improvements have been taken on board and the scope of the QMS expanded to include servicing and maintenance activities.
SPS Trials Second SMD Reflow Oven
/in Facilities /by spssps15SPS is trialling an Asscon VP450 small batch vapour phase oven kindly provided by Zen Production Equipment Ltd. (www.zpel.co.uk). We were very impressed by the professional and open approach of Zen both in terms of sales and on-site commissioning support. The very first PCB trialled with the unit was a complex design incorporating significant copper floods with larger SMD components as well as other areas with just signal electronics. Our experienced production technician was very impressed with the excellent quality solder joints that were immediately evident and the simple operation of the machine. As a result of this initial trial and other subsequent successful uses of the machine, the decision was made to go ahead and purchase.
BSI carry out ISO9001:2008 pre-assessment
/in Qualifications /by spssps15As the next step to achieving ISO9001:2008, SPS have engaged the services of world renowned British Standards Institute (BSI) to carry out a “pre certification” audit of its existing Quality Management System. This was duly carried out with no issues found but just a few suggestions for improvement. These suggestions have been taken on board and minor changes made. BSI have now been fully engaged to carry out stage 1 and stage 2 external auditing with a view to achieving certification in Q1 2016.
ISO9001:2008 Internal Auditor Training
/in Qualifications /by spssps15In anticipation of seeking certification to ISO9001:2008, two SPS staff have attended BSI’s internal auditor course which was held over two days in York. Both Alan Yarker (Production and Quality Manager) and Peter Moriarty (Principal R&D Engineer) found the course to be very helpful in providing a structured approach to auditing. It also allowed them to get some specific key questions answered by people who had clearly been auditing for many years. Having fully trained internal auditors was viewed as being the first key step to achieving certification which is targeted at Q1 16.
Review of in-house SMD Soldering
/in Facilities /by spssps15Having our own internal capability for high quality assembly of SMD PCBs for prototyping and small manufacturing batch runs has always been essential to meet customer lead times. Without a large multi-zone heater reflow oven and the possibility of tweaking parameters to optimise production yield, this is not a straightforward task. This has been compounded by the move to lead-free soldering and the same PCB having a large range of size and weight of components and tracking / flooding. Historically a modest size convection reflow oven has been used by SPS but it was apparent that a higher performance oven would be required for future use. An internal review of different reflow technologies was carried out by our production department and advice sought from various suppliers. After poor results from trialling a popular oven specifically designed for low volume / batch work, advice was sought from Electronics Yorkshire. They recommended using vapour phase technology which SPS was familiar with as a technology as it has been used for many years for soldering copper base plates to the underside of the DBC in isolated power modules.
IPC-A-610 Certified Trainer
/in Qualifications /by spssps15We are fortunate in having a very experienced production technician (Elizabeth Thewlis) who joined SPS in June 2012 having previously worked for many years in the power electronics industry. Liz had previously been trained to IPC-A-610 but her certification had lapsed. Given her experience it was an obvious decision to ask her to take the IPC-A-610 certified instructor course at Electronics Yorkshire so she could then instruct other members of staff. She duly completed the course in July 2015.
New Member of the Team
/in Facilities /by spssps15As a result of a significant increase in both manufacturing and development work, SPS has taken on another full time engineer. Kyriakos Papameletis (Kyri) recently completed his Master’s degree at Leeds University in “Electrical Engineering and Renewable Energy Systems”. He will be assisting with supporting test and debug work in manufacturing as well as development work on the design side of the business. This means that we now have 7 Engineers on the development side of the business who all studied at Leeds University and between us we have 3 PhD.s, 3 Masters and 5 Bachelor Degrees!! Two of us are also Chartered Engineers – the equivalent of P.E for our North American colleagues.
Equipment Update
/in Facilities /by spssps15After a 1 month trial, SPS has gone ahead with purchasing a combined frequency response and wide bandwidth impedance analyser (PSM1735 + IAI fixture) manufactured by UK company Newton’s 4th Limited. Having access to this piece of equipment will allow more accurate and reliable characterisation of the frequency response of the significant range of complex control systems that SPS develops.
The previous piece of equipment SPS used for this was limited in its ability and was reaching the end of its life. The Impedance Analysis Interface module will also assist SPS with assessing the performance of both standard and custom designed components all the way up to 35 MHz which is an essential part of switched-mode power conversion and Electromagnetic Compatibility development work.
